Place of Origin:
China
Brand Name:
WENYOU
Certification:
SGS/UL/ customized certificate
Model Number:
9218
Electrical epoxy resin is an electrical adhesive resin, which is specially designed for electrical insulation. It has a Tg (DSC) of 100-120℃ according to ISO11357-2, a flexural strength of 110-140N/ Mm2 according to ISO178, and a cure temperature of 130-140℃. Its flammability (4mm) is HB, and its cure shrinkage is 0.6-0.8% according to ISO178. This electrical epoxy resin has excellent electrical insulation performance and high flexural strength, as well as low cure shrinkage.
| Product Name | Electrical Epoxy Resin |
|---|---|
| Cure shrinkage | ISO178 0.6-0.8% |
| Tensile Strength | ISO527 60-85N/ Mm2 |
| Flexural strength | ISO178 110-140N/ Mm2 |
| Cure Temperature | 130-140℃ |
| Viscosity at 25℃ | ISO12058 5.5-8.5 MPa.s |
| Tg (DSC) | ISO11357-2 100-120℃ |
| Epoxy value | ISO3001 4.4-4.9 |
| Loss factor | 0.02 |
| Color/Appearance | ISO12058 Light Yellow-colorless Liquid |
| Keywords | Electrical_Adhesive_Resin, Electrical_Insulation_Resin, Electrical_Insulation_Resin_System |
Electrical epoxy resin is an electrical adhesive resin from China, specifically produced by WENYOU, with model number 9218 and certification of SGS/UL/customized certificate. It is a light yellow-colorless liquid with dielectric strength of 30 Kv/mm, compressive strength of 150-200N/ Mm2, and cure shrinkage of 0.6-0.8%. It has a minimum order quantity of 240 KG and delivery time within 10 days. The price for this electrical epoxy resin is $2.6 per 20KG/ 220kg and payment terms of L/C,T/T. WENYOU is capable of supplying up to 200Ton/month of Electrical Epoxy Resin with cure temperature of 130-140℃.
Brand Name: WENYOU
Model Number: 9218
Place of Origin: China
Certification: SGS/UL/ customized certificate
Minimum Order Quantity: 240 KG
Price: $2.6
Packaging Details: 20KG/ 220kg
Delivery Time: within 10days
Payment Terms: L/C,T/T
Supply Ability: 200Ton/month
Dielectric Strength: 30 Kv/mm
Product Name: Electrical Epoxy Resin
Cure shrinkage: ISO178 0.6-0.8%
Impact Strength: ISO179 10-18kJ/ M2
Tg (DSC): ISO11357-2 100-120℃
We provide customized service of Electrical Adhesive Resin, Electrical Insulation Resin, Electrical Adhesive Resin and Electrical Epoxy Resin with high quality to meet your demand.
At XYZ, we are dedicated to providing the highest quality of technical support and service for our Electrical Epoxy Resin product. Our team of experienced engineers is available to answer any questions you may have about the product and provide technical advice and assistance. We also provide ongoing maintenance and support services to ensure your product is always running at its best. To ensure your satisfaction, we offer a comprehensive warranty program that covers all parts and labor for the product. If you ever encounter any issues with the product, we are here to help.
Packaging and Shipping Electrical Epoxy Resin
Electrical epoxy resin should be packaged in a sealed container to prevent any contamination. All packaging materials should be free from any contaminants that could potentially affect the quality of the product. Before shipping, the containers should be inspected for any signs of leakage or other damage.
When shipping electrical epoxy resin, it should be done so in accordance with applicable regulations and safety standards. All packages should be clearly labeled with the product name, type, and quantity. Temperature-controlled shipping methods should be used if necessary to ensure the epoxy resin remains in good condition during transit.
