Excellent transformer maker epoxy resin producer environment friendly chemicals

Excellent transformer maker epoxy resin producer environment friendly chemicals

Excellent transformer epoxy resin

Environment friendly transformer epoxy resin

Chemicals transformer epoxy resin

Place of Origin:

China

Brand Name:

wenyou

Certification:

ISO9001, ISO14001, SGS, and UL

Model Number:

8213

Contact Us
Request A Quote
Excellent transformer maker epoxy resin producer environment friendly chemicals
Excellent transformer maker epoxy resin producer environment friendly chemicals Excellent transformer maker epoxy resin producer environment friendly chemicals Excellent transformer maker epoxy resin producer environment friendly chemicals
Product Details
Classification:
Double Components Adhesives
Usage:
Dry-type Transformers, 10-66kV Current Transformers, Voltage Transformers, And Other Related Products
Application:
Electrical Insulators For Medium And High Voltage Applications
Appearance Of Epoxy Resin:
Transparent Viscous Liquid
Appearance Of Hardener:
Light Yellow Liquid
Viscosity At 25°C:
3000 - 6000mPa.s
Density At 25°C:
1.16 - 1.20g/cm3
Vapor Pressure At 25°C:
＜ 0.01Pa
Flash Point:
Around 135°C
Description:
Excellent Transformer Maker Epoxy Resin Producer Environment Friendly Chemicals
Payment & Shipping Terms
Minimum Order Quantity
20kg/pail as sample
Price
Negotiable
Packaging Details
20kg/pail, 220kg/barrel, 1200kg/tank
Delivery Time
7 -10 work days
Payment Terms
Normally L/C, T/T
Supply Ability
Plenty of raw material in stock
RELATED PRODUCTS
Good price Strong weather endurance Transformers Epoxy Resin outdoor CT VT raw material online Video

Strong weather endurance Transformers Epoxy Resin outdoor CT VT raw material

Get Best Price
Good price Excellent transformer maker epoxy resin producer environment friendly chemicals online Video

Excellent transformer maker epoxy resin producer environment friendly chemicals

Get Best Price
Good price Reliable raw material epoxy resin liquid fast delivery stable products online Video

Reliable raw material epoxy resin liquid fast delivery stable products

Get Best Price
Good price Casting epoxy resin for dry - type transformer Indoor use thermal endurance material online Video

Casting epoxy resin for dry - type transformer Indoor use thermal endurance material

Get Best Price
Contact Us
86-21-64308192
Contact Now
Product Description

Brief Introduction

Environmentally Friendly Epoxy Resin for Transformer Manufacturing

LE-8213 is a modified saturated cyclic aliphatic epoxy resin system.

LH-8213 is a modified weather-resistant anhydride hardener.

Applications

  • Ideal for electrical insulation in medium and high voltage applications.
  • Suitable for dry-type transformers, 10-66 kV current transformers (CT), voltage transformers (PT), and other related components.

Processing Methods

  • Conventional Gravity Casting Process under vacuum.
  • Automatic Pressure Gelation Process (APG).
  • The production process can be tailored to align with the client's current manufacturing methods.

Properties

  • This two-component saturated cyclic epoxy resin system is free of pre-mixed fillers and remains liquid at room temperature.
  • Features low curing shrinkage, excellent dimensional stability, superior processing performance, and outstanding mechanical and electrical properties.

Formulation



Epoxy resin LE-8213 100 pbw
Hardener LH-8213 100 pbw
Filler Silica Powder 300-380 pbw
Color paste LC series * Appropriate



Package Image



Excellent transformer maker epoxy resin producer environment friendly chemicals 0



Shipment image



Excellent transformer maker epoxy resin producer environment friendly chemicals 1



Example application image



Excellent transformer maker epoxy resin producer environment friendly chemicals 2
